SKU: l34o5d4dpn
| ABSTone Ring Included | No |
|---|---|
| Center Hole Diameter(IN) | 3.54 |
| Center Hole Diameter(MM) | 90 |
| Construction | Full Cast |
| Conventional Or Drum In Hat Type Rotor | Drum-In-Hat |
| Cross Drilled | No |
| Directionalor Non Directional Brake Surface | Non-Directional |
| Discard Thickness(IN) | 0.79 |
| Discard Thickness(MM) | 20 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter(IN) | 5.31 |
| Mounting Bolt Hole Circle Diameter(MM) | 135 |
| Mounting Bolt Hole Diameter(IN) | 0.61 |
| Mounting Bolt Hole Diameter(MM) | 15.6 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness(IN) | 0.87 |
| Nominal Thickness(MM) | 22 |
| Outside Diameter(IN) | 13.23 |
| Outside Diameter(MM) | 336 |
| Overall Height(IN) | 1.77 |
| Overall Height(MM) | 45 |
| Part Number | BR901372-01 |
| Rust Resistant Coating | Yes |
| Slotted | No |
| Solid Or Vented Type Rotor | Vented |
| Year | Make | Model |
|---|---|---|
| 2015, 2016, 2017 | FORD | F150 PICKUP |
| Specifications | Descriptions |
|---|---|
| No Specifications | |
